Single Sided PCB

Get a Price/Quote

MOQ : 100 Pieces

Single Sided PCB Specification

Impedance
Not Controlled

Soldermask
Green Epoxy Ink

Min. Line Width
0.15 mm

Flame Resistance Level
UL94V-0

Min. Line Spacing
0.15 mm

Board Type
Rigid

Silkscreen
White or Yellow, Single Side

Test
100% Open/Short Circuit Tested

Hole Size
Min 0.3 mm

Insulation Resistance
>10^12

Voltage Endurance
1500V AC/min

Product Type
Single Sided PCB

Base Material
FR4 Glass Epoxy

Surface Finish
HAL (Hot Air Leveling)

Copper Thickness
35 m (1 oz/ft2)

Board Thickness
1.6 mm

Color
Green

Panel Size
Standard 18 x 24 or custom

Electrical Components
Not Populated (Bare Board)

Number Of Layers
1 Layer

Maximum Current Carrying Capacity
Varies with trace width, typically up to 2A for standard traces

Surface Mount Capability
No (for single sided)

Packaging
Shrink Wrapped or Bulk Packed

Storage Conditions
Dry and Clean Environment

Board Shape
Rectangular, Customizable

Application Areas
Consumer Electronics, LED Lighting, Power Supply, DIY Projects

RoHS Compliance
Yes

Operating Temperature Range
-40C to +130C

Single Sided PCB Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash Against Delivery (CAD), Cash on Delivery (COD), Cash in Advance (CID)

Supply Ability
1000 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About Single Sided PCB

Pick Yours: a stellar, single-sided PCB engineered for both special and general applications. Crafted from rigid FR4 glass epoxy, this affordable solution boasts an operating temperature from -40C to +130C and exceptional insulation resistance above 10^12. Our uncommon board features customizable sizing-standard 18x24 inches or custom-and a classic green soldermask with options for silkscreen in white or yellow. With 1 oz copper, 1.6 mm thickness, and RoHS compliance, you enjoy reliability, terrific flame resistance (UL94V-0), and a surface finish of HAL. Shrink wrap or bulk packaging available. Designed for robust performance in consumer electronics, LED lighting, and DIY projects.

Versatile Applications & General Use

Single Sided PCBs are specifically engineered for both specific and general use across industries. Their plant applications span machinery panel controls, dedicated consumer products, and power supply assemblies. The robust and rigid nature of each board makes them ideal for a variety of application areas including consumer electronics, LED lighting, and DIY project innovations. These boards deliver uncommon reliability and are adaptable for many industry-standard implementations, making them the perfect fit for broad application needs.

FOB Port, Sample Policy & Domestic Market Reach

Our single sided PCBs are available for shipment via key domestic ports, ensuring swift logistics for bulk or special orders. With samples readily available, you can evaluate quality before committing to a purchase. The main domestic market coverage ensures that stock is ready and the list price is highly competitive for Indian manufacturers and service providers. Experience seamless access and affordability right at your doorstep, tailored for the domestic market's diverse electronic requirements.

FAQ's of Single Sided PCB:

Q: How can I order a customized single sided PCB for my specific application?

A: To order a customized single sided PCB, simply contact us with your specific requirements regarding panel size, hole dimensions, and silkscreen color. Our team will guide you through the design and ordering process to ensure the board perfectly matches your application.

Q: What key benefits does this uncommon single sided PCB offer compared to standard options?

A: This PCB features a stellar combination of affordability, robust temperature tolerance (-40C to +130C), UL94V-0 flame resistance, and 100% open/short circuit testing. Its customizable features and RoHS compliance make it an ideal, reliable choice for diverse electronic applications.

Q: When should I use a single sided PCB over other types?

A: Single sided PCBs are best suited for applications requiring straightforward circuit designs and economical production. They are ideal for consumer electronics, power supplies, LED lighting, and DIY projects that don't require surface mount technology or multi-layer functionality.

Q: Where can these PCBs be implemented within a factory setting?

A: These PCBs can be installed in plant applications such as control panels, process automation devices, and as power supply boards within manufacturing equipment, offering durable, reliable circuit solutions for various industrial and assembly line uses.

Q: What is the process for ensuring the electrical safety and performance of these boards?

A: Each single sided PCB undergoes 100% open/short circuit testing, ensuring no electrical faults. Manufactured from flame-retardant FR4 and featuring insulation resistance greater than 10^12, every board is verified for voltage endurance up to 1500V AC/min for stellar operational safety.

Q: How should single sided PCBs be stored for optimal longevity?

A: For maximum lifespan and performance, single sided PCBs should be stored in a dry, clean environment. Use original shrink wrap or bulk packaging to protect the boards from moisture and contaminants until ready for use.
